SW-020B Carbine Replica
Firearms in bullpup system (sometimes referred to as stockless) have a long tradition and an equal amount of enthusiasts as well as skeptics. One of the advantages of this construction can be hardly ignored - it is the possibility of implementation of a really long and effective barrel, whilst maintaining a relatively compact size of the firearm. It is important to note the aesthetic value as well - bullpup firearms are simply unique and they cannot be mistaken for anything else.
Similarly to the live firearm, the receiver of the replica was made from durable polymer. Metal parts include: entire front of the replica with the external barrel, top RIS rail and miscellaneous elements such as the shell ejection window plate or flash hider.
The rear as well as the front part of the replica feature tactical sling swivels. Access to the Hop-Up adjustment knob is gained in a traditional way - after pulling back the charging handle and uncovering the shell ejection window. The handle can be locked in rear position. What is characteristic for this construction is that shell ejection windows are located on both sides of the receiver, which makes it comfortable to use for a left-handed User as well. The flash hider sits on a 14 mm left-handed thread.
The battery of the replica is stored inside the stock (if one can use such a word in the case of a stockless design). In order to access the battery, one needs to remove the rubber stock pad. No tools are necessary for that operation because it is attached by being pressed into its place. Disassembly of the entire replica into two parts also lasts mere seconds. It is necessary to access the Hop-Up chamber and internal barrel. In order to do that, it is necessary to press a metal pin - a lock - and afterward split away from the construction into 2 parts - the receiver and front part with the barrel.
Features a metal, top RIS 22 mm mounting rail that allows for the attachment of chosen optics or iron sights.
The replica features a two stage trigger, whose first stage causes the replica to fire in semi mode and full pull - fully automatic. The safety is located at the pistol grip and can be operated from both sides. In the front, under the barrel is a characteristic for the rifle, foldable 3-setting vertical forward grip.
The replica has a quick spring change system that allows with a minimal amount of time to change the main spring. There is no need to take out the gearbox and disassemble the entire construction. All that is necessary is to remove the stock pad, unscrew the plastic cap and through the opening in the back side of the gearbox pull out the slide with the spring. The system allows to rapidly and quickly adapt the power of the replica to the conditions expected on the playing field without the necessity to have access to a workshop or a set of special tools. This allows to easily guarantee an ideal compromise between the effectiveness of fire and safety for the user himself as well as other participants.
The replica comes with a polymer Hi-Cap magazine with a capacity of up to 330 BBs.
Pakket bevat:
- Instructie
- Hi-Cap Magazjin
- Replica
Pakket exclusief:
- De set is exclusief batterij en oplader
Batterij inbegrepen Akumulator NiCd cechuje się dużą wydajnością prądową, ale występuje w nich uciążliwy efekt pamięci. Powinny być rozładowywane i ładowane w pełnych cyklach, tj. zaleca się pełne rozładowanie, a po rozładowaniu należy akumulator niezwłocznie naładować nie pozostawiając go na dłużej w stanie rozładowanym. Akumulatory NiMH charakteryzują się szybszym czasem samorozładowania i krótszą żywotnością - z drugiej strony, osiągają one ok. 30% więcej pojemności. | Nee |
| Kleur | Olive Drab ( groen ) |
| Product lengte [cm] | 81 |
| Product gewicht [g] | 4900 |
| Voortstuwing | Electrisch |
| Materiał | Metal Plastic |
| Mondingssnelheid [FPS] Jest to prędkość kulki, w momencie opuszczenia przez nią lufy repliki. Mierzona jest w FPS (stopy na sekundę). 1 FPS = 0,3 m/s 1 J = 99 m/s 1 J = 326,7 FPS | 420 |
| Vuur modes | Full-auto Semi-auto |
| Gearbox versie Oznaczenia v2, v3, v6 nie oznaczają stopnia zaawansowania mechanizmu ,a jedynie kształt zastosowanego szkieletu, który dobierany jest przez producenta w zależności od możliwości korpusu repliki. Przykładowo, repliki z rodziny M4/M16, MP5, mają gearbox v2, natomiast rodzina AK czy G36 gearbox v3. | Gearbox v3 modified |
| Hop-Up System Hop-Up służy do podkręcania kulki podczas wystrzału (wprowadzenie jej w obrót rotacyjny), dzięki któremu, przedłuża ona swój tor lotu. Działające prawa fizyki, powodują iż obrót kulki unosi ją do góry, natomiast siły grawitacyjne naturalnie ją przyciągają. Odpowiednie wyregulowanie Hop-Up, spowoduje wyrównanie tych dwóch zjawisk, co zaowocuje długim i prostym lotem na dłuższym dystansie oraz większeym skupieniem strzału (poprawienie celności). | Ja |
