SA-H12 ONE™ Carbine Replica
SA-H12 carbine replica by Specna Arms is made largely of a uniform zinc and aluminum alloy, reinforced with steel elements in the most vulnerable points of the replica (steel elements - all the screws, pins and tactical sling swivels). Both the stock storing the battery and the pistol grip were made from polymer. The receiver of the replica and RIS handguard have undergone the process of anodizing, which guarantees high degree of protection against corrosion. The paint was applied via a process of powder coating, after having the surface undergo the process of sandblasting prior to the application of paint. This provides a much higher than usual resistance of the applied paint to abrasion. The receiver bears manufacturer markings.
The replica’s parts are very well aligned - in a way that could be thus far noticed solely in replicas by such top-tier manufacturers as G&P or Classic Army, the replica is also perfectly balanced. This allows for an almost ideal maneuverability of the replica and its weight is almost unnoticeable once the replica has been shouldered.
The replica features a quick spring change system, so-called Enter & Convert™. Due to that system, it is possible to rapidly and quickly adapt the power of the replica to the conditions expected on the playing field without the necessity to have the access to a workshop or a set of special tools - once the gearbox has been taken out of the replica’s body, the process of spring change lasts literally seconds.
The advantages of Enter & Convert™ system are hard to overstate. In the light of the current tendency in the whole Europe to use legal limitations regarding the muzzle velocity of replicas or internal regulations inside various groups, the system guarantees the User a varied set of possibilities and much freedom. Enter & Convert™ system allows with a minimal amount of time to exchange the main spring, thus to customize the muzzle velocity towards the area of the game in such a way so as to guarantee an ideal compromise between the effectiveness of fire and safety for the User himself as well as other participants.
The replica is fully compatible with LiPo and LiFe batteries. Due to a base muzzle velocity of ~410 FPS provided by the main spring installed by default by the manufacturer, the replica is perfect for operating on a medium range. The set also includes an M90 spring, which allows to reduce the muzzle velocity to ~310 FPS and as a result to adapt the replica for close-ranged and indoor operations.
A reinforced at the cylinder level gearbox contains a steel spring guide that is an element of Enter & Convert™ system and mounted on 8 mm ball bearings and washers steel gears. The system is secured with four anti-reversal latches. Also, a type 2 cylinder and a steel circuit-breaker. At stock, the replica features a precise, rotary, polymer Hop-Up chamber that allows for very precise and stable BB spin adujstment.
The replica is equipped with a top RIS 22 mm rail, a modular handguard and an adjustable stock. The top RIS rail features metal flip-up iron sights, which can be freely detached in order to make room for the attachment of a chosen optoelectronic aiming device. Due to the extendable stock with an anti-slip stock pad, it is possible to adapt the replica’s length to the body type and preferences of the User. The flash hider is based on a 14 mm left-handed thread, which allows the attachment of a silencer in its place.
The replica features double-sided manipulators: fire mode selector, magazine release button and mock Bolt-Catch release button.
In order to enhance the realism of the game, the replica also features an operational bolt-catch mechanism.
The replica comes with a steel, 300 BB, Hi-Cap magazine.
The set does not include a battery or a charger.
The set includes:
- fixed iron sights
- additional main spring
Blow back is a simulation system of the cocking lever - it imitates the work of it as the equivalent sharp. This system raises the realism and adds a lot more experience during shooting.
|Product weight [g]|
|Muzzle velocity [FPS]|
It is the spped of bb, while its leaving the innerbarrel of replica. This speed is measured in FPS (Feet Per Second).
1 FPS = 0,3 m/s
1 J = 99 m/s
1 J = 326,7 FPS
Indications v2, v3, v6 does not mean the level of advance, but only shape of gearbox skeleton which was used and selected by the manufacturer depending on the capabilities of the body of the replica. For example, a models of the M4/M16 family, MP5, have a v2 gearbox, while the AK family have gearbox v3.
Hop-Up system is used for overclocking bb during the shot (putting it in rotation), through which, it extends its flight path. Acting laws of physics make that bb lift up, while the gravitational force take it down. Appropriate adjustment of Hop-Up, will compensate for these two factors, which result in long and straight flight for longer distance and be greater focus shot (to improve accuracy).
|Inner barrel length [mm].|
|Length minimal [mm]|
|Magazine capacity [pcs.]|
|Quick Spring Change system|
|Type of plug|
|Type of thread on the barrel|
